Adastra 100V Switchable Slave Amplifier 240W

Price checked 2026-07-15 · Image: merchant feed

1U Rack Mountable. Efficient and Lightweight Class-D Amplifiers. Line In and Out on RCA or Euroblock Terminals. 24V Mute Contacts for Alarm Panel Muting. 100V Signal Input for Extending Existing S... Switchable Speaker Outputs between 100V or Low ImpedancePower Supply: 175-2654Vac- 50/60Hz Power 8 Ohms: 120W (RS121) & 240W (RS240) Signal Inputs: RCA/Terminal (Slave In) or Screw Terminal (100V In) Speaker Outputs: Screw Terminals Dimensions: 433 x 267 x 44mm Weight: 4.8Kg (RS121) & 5.8kG (RS240).

High power class-D 100V line slave amplifiers in a rack-mountable housing. Slave inputs accept standard line level audio from a mixer or RM series mixer amplifier. Slave outputs can be cascaded onto further RS slaves to build larger systems. All line level inputs are connectable via RCA sockets or hard-wired via removable screw terminals. A further removable screw terminal is provided for 100V input- which enables the RS series slave amplifier to extend an existing 100V installation by connecting directly to the 100V speaker feed- or indeed from a long distance 100V feed using standard double-insulated cable. A 24V terminal is provided for connection to a security or alert panel to mute the output if required during alarm triggering.
